🌐 Archify Instant AI Diagram Generator

Archify Instant AI Diagram Generator automatically transforms code files and system ideas into interactive, dark-mode visual maps using AI agents.

⚡ 3-Step Execution Workflow

Step 1: Input	Step 2: AI Action	Step 3: Result
Read Python files from inputs/sample_repo/	Ollama Agent parses SKILL.md & builds visual map	Generates interactive web diagram & summary report

---

🛠️ Tech Stack

• Language: Python 3.9+
• AI Agent Integration: Ollama API & Local GGUF models
• Diagram Compiler: Archify Engine (Node.js renderer)
• Output Formats: Standalone HTML + Inline SVG

---

🚀 Quick Start Guide

1. Installation

Install required dependencies in your Windows PowerShell terminal:

pip install -r requirements.txt

2. Install & Run Ollama Model

Pull and run the required Ollama model (`deepseek-v4-pro-qwen-4b-mtp:latest`):

ollama pull deepseek-v4-pro-qwen-4b-mtp:latest

3. Run Application

Execute the main generator script to analyze the sample codebase inside `inputs/sample_repo/`:

python main.py

---

📂 Project Repository Structure

Archify/
├── inputs/
│   └── sample_repo/
│       ├── api_gateway.py
│       ├── auth_service.py
│       ├── cache_cluster.py
│       └── data_pipeline.py
├── main.py
├── requirements.txt
└── README.md

---

🌟 5 Key Use Cases

1. Automated App Service Mapping: Turn complex backend repos into visual component maps instantly.
2. Pull Request Code Reviews: Compare system maps before and after code merges to catch unexpected dependencies.
3. **Bu
